OPERATING VOLTAGE DC 9-15V
OUTPUT POWER 4,000W * 1CH (@14.4V/1 OHM)
OUTPUT POWER 2,000W * 1CH (@14.4V/2 OHM)
OUTPUT POWER 1,000W * 1CH (@14.4V/4 OHM)
INPUT SENSITIVITY 0.2-6V
SNR≥ 95 dB
FREQUENCY RESPONSE15 - 270 Hz
LOW PASS FILTER35-250Hz
SUBSONIC FILTER10-50Hz
HIGH PASS FILTER-
PHASE REGULATION0 - 180°
MIN. LOAD ON SINGLE CHANNEL1 OHM
MIN. LOAD IN BRIDGE MODE-
MIN. LOAD IN LINK MODE2 OHM (MASTER/SLAVE LINK)
SIZE (L*W*H)22.4*10.0*2.48 inches
