EMF Audio Banhammer 15"

DISCONTINUED, to be replaced by a version 2

Features:

• Power Handling - 2,000 watts RMS
• Xmax - 35mm one way
• 4 inch 4 layer copper voice coil rated up to 500 degrees Fahrenheit
• 10" linear roll spiders
• High velocity pole vent
• Additional rear gap venting
• 4 gauge spring loaded terminals
• High roll foam surround
• Designed for daily musical use with low bass and exceptional bandwidth
• Tooled magnet boot

Banhammer 15"

Recommended enclosure: 3.5-4 cu. ft ported (also 4th order friendly)

2,000 watts RMS
Fs         =     25.4331 Hz
Qes        =      0.5596
Qms        =      4.6929
Qts        =      0.5000
Vas        =     53.4885 L
Mms        =    601.3193 g
35mm xmax one-way

10.185" mounting depth
14.125" cut-out
15.625" outside diameter with gasket
